The Story
Bring professional-level wireless into your space with the Tenda I9. Designed for ceiling or wall installation, this access point operates at N300 speeds over the 2.4 GHz band, delivering fast, stable WiFi across offices, cafés, classrooms, or multi-room homes. Dual internal omni-directional antennas provide strong signal coverage and better penetration through walls. With both PoE (802.3af) and a 12 V DC power option, you get flexible installation that avoids running extra power cables.
Management is simple: assign SSIDs, set up VLANs or guest networks, adjust transmit power, and limit client access through the built-in web interface or via centralized controller. Security support includes WPA/WPA2, SSID hiding, MAC address filtering and client access rules. Under 8 W power consumption keeps energy use low, and the sleek, minimal design keeps it discreet when mounted in ceilings or high on walls.
Key Features
-
Delivers up to 300 Mbps on 2.4 GHz (802.11b/g/n) wireless band
-
Ceiling/wall mount design with dual internal high-gain omni antennas for strong 2.4 GHz coverage
-
Supports PoE (802.3af) and 12 V DC power for flexible installation options
-
Multiple SSIDs, SSID-VLAN bindings and guest network capabilities for separation of traffic
-
Adjustable transmit power & client access rules (limit weak-signal clients) to maintain performance
-
WPA/WPA2 encryption, SSID hiding, MAC filtering for security
-
Web UI or wireless controller support for centralized management
-
Low power draw, < 8 W under typical operation
Specs
-
Wireless Standard: IEEE 802.11b/g/n (single 2.4 GHz band)
-
Maximum Data Rate: 300 Mbps
-
Ethernet Port: 1 × 10/100 Mbps RJ-45
-
Power Options: 802.3af Power over Ethernet or 12 V DC (1 A)
-
Antennas: 2 internal omni-directional MIMO antennas
-
Supported SSIDs: up to 4, plus guest / VLAN options
-
Mounting Styles: ceiling or wall installation
-
Transmit Power: approx. 20 dBm ±1.5 dBm
-
Dimensions: 184 × 184 × 38 mm
-
Power Consumption: less than 8 Watts maximum
-
Security: WPA-PSK, WPA2-PSK, MAC filtering, SSID hiding
-
Operating Temp: −10 °C to 40 °C; Storage Temp: −30 °C to 70 °C; Humidity: 10-90% non-condensing
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Bring professional-level wireless into your space with the Tenda I9. Designed for ceiling or wall installation, this access point operates at N300 speeds over the 2.4 GHz band, delivering fast, stable WiFi across offices, cafés, classrooms, or multi-room homes. Dual internal omni-directional antennas provide strong signal coverage and better penetration through walls. With both PoE (802.3af) and a 12 V DC power option, you get flexible installation that avoids running extra power cables.
Management is simple: assign SSIDs, set up VLANs or guest networks, adjust transmit power, and limit client access through the built-in web interface or via centralized controller. Security support includes WPA/WPA2, SSID hiding, MAC address filtering and client access rules. Under 8 W power consumption keeps energy use low, and the sleek, minimal design keeps it discreet when mounted in ceilings or high on walls.
Key Features
-
Delivers up to 300 Mbps on 2.4 GHz (802.11b/g/n) wireless band
-
Ceiling/wall mount design with dual internal high-gain omni antennas for strong 2.4 GHz coverage
-
Supports PoE (802.3af) and 12 V DC power for flexible installation options
-
Multiple SSIDs, SSID-VLAN bindings and guest network capabilities for separation of traffic
-
Adjustable transmit power & client access rules (limit weak-signal clients) to maintain performance
-
WPA/WPA2 encryption, SSID hiding, MAC filtering for security
-
Web UI or wireless controller support for centralized management
-
Low power draw, < 8 W under typical operation
Specs
-
Wireless Standard: IEEE 802.11b/g/n (single 2.4 GHz band)
-
Maximum Data Rate: 300 Mbps
-
Ethernet Port: 1 × 10/100 Mbps RJ-45
-
Power Options: 802.3af Power over Ethernet or 12 V DC (1 A)
-
Antennas: 2 internal omni-directional MIMO antennas
-
Supported SSIDs: up to 4, plus guest / VLAN options
-
Mounting Styles: ceiling or wall installation
-
Transmit Power: approx. 20 dBm ±1.5 dBm
-
Dimensions: 184 × 184 × 38 mm
-
Power Consumption: less than 8 Watts maximum
-
Security: WPA-PSK, WPA2-PSK, MAC filtering, SSID hiding
-
Operating Temp: −10 °C to 40 °C; Storage Temp: −30 °C to 70 °C; Humidity: 10-90% non-condensing
