The Story
The Ultimate Platform for Gamers and Creators
Powered by GeForce RTX 40 Series and DLSS 3
New Streaming Multiprocessors
Up to 2x performance and power efficiency
Fourth-Gen Tensor Cores
Up to 4x performance with DLSS 3 vs. brute-force rendering
Third-Gen RT Cores
Up to 2x ray tracing performance
CHANGE THE GAME
Ascend to a superior experience with SUPRIM. See, hear, and feel a profoundly elevated graphics card built with high-quality materials and assembled with enthusiast features.
01. SHARP LOOKS
The second iteration of SUPRIM inherits the exterior design philosophy of its predecessor, with a brushed metal cover, octagon-shaped fan cutouts and chevrons around each fan.
02. POLISHED EDGES
Beveled edges are polished several times with a diamond-tipped cutter to achieve a mirror-finish. Clean sharp lines emphasize the metal construction to sight and touch.
03. FINISHING TOUCHES
The motif of straight lines continue around the fans with octagonal cutouts featuring polished 45-degree beveled edges.
TRI-FROZR 3S THERMAL DESIGN
Upgraded fans, airflow control, and other thermal innovation make TRI-FROZR 3S the best air-cooling solution yet from MSI.
TORX FAN 5.0
TORX FAN 5.0 incorporates design improvements that result in +23% increased airflow compared to an axial fan.
METAL BACKPLATE
Thermal pads under the sturdy metal backplate provide additional cooling while the flow-through ventilation reduces trapped heat.
ZERO FROZR
The fans completely stop when temperatures are relatively low, eliminating all noise when active cooling is not needed. The fans will automatically start spinning again when the heat is on during gaming.
DOUBLE-BALL BEARING
Two sets of durable ball bearings spin the TORX FANs for years of intense and lengthy gaming sessions.
Specifications:
|
MODEL NAME |
GeForce RTX™ 4070 Ti SUPRIM X 12G |
|
GRAPHICS PROCESSING UNIT |
NVIDIA® GeForce RTX™ 4070 Ti |
|
INTERFACE |
PCI Express® Gen 4 |
|
CORE CLOCKS |
Extreme Performance: 2790 MHz (MSI Center) |
|
CUDA® CORES |
7680 Units |
|
MEMORY SPEED |
21 Gbps |
|
MEMORY |
12GB GDDR6X |
|
MEMORY BUS |
192-bit |
|
OUTPUT |
DisplayPort x 3 (v1.4a) |
|
HDCP SUPPORT |
Y |
|
POWER CONSUMPTION |
285 W |
|
POWER CONNECTORS |
16-pin x 1 |
|
RECOMMENDED PSU |
750 W |
|
CARD DIMENSION (MM) |
338 x 142 x 73 mm |
|
WEIGHT (CARD / PACKAGE) |
2019g / 3224g |
|
DIRECTX VERSION SUPPORT |
12 Ultimate |
|
OPENGL VERSION SUPPORT |
4.6 |
|
MAXIMUM DISPLAYS |
4 |
|
G-SYNC® TECHNOLOGY |
Y |
|
DIGITAL MAXIMUM RESOLUTION |
7680x4320 |
