MikroTik RB951Ui-2HnD - 2.4GHz Wireless Access Point with 5 Ethernet Ports and PoE Output

The MikroTik RB951Ui-2HnD is a robust and compact wireless router tailored for small office and home office (SOHO) networks. Powered by a 600 MHz Atheros AR9344 CPU and 128 MB of RAM, it delivers reliable performance for streaming, VoIP, and file sharing. Its integrated 2.4 GHz 802.11b/g/n access point reaches up to 300 Mbps, while five 10/100 Ethernet ports and a USB 2.0 port expand wired connectivity and peripheral support.

Featuring dual power options (8–30 V passive PoE or DC jack) and a passive PoE output on port 5 (up to 500 mA), the RB951Ui-2HnD simplifies deployments by powering other devices—such as cameras or additional access points—directly from the router. Run advanced routing, firewall, and wireless features via RouterOS v4 through its web interface or Winbox utility. With passive cooling and a broad operating temperature range, this unit is built to run continuously in demanding environments.

---

Key Features

• 600 MHz AR9344 CPU & 128 MB RAM: Smooth multitasking and throughput.

• 2.4 GHz 802.11b/g/n Wi-Fi: Dual-chain AP with integrated 2.5 dBi antennas for up to 300 Mbps.

• Five 10/100 Ethernet Ports: Gigabit-capable uplink and LAN connections.

• USB 2.0 Port: Connect 3G/4G modems, storage devices, or other peripherals.

• PoE In/Out Functionality: Passive PoE input and PoE output on port 5 (500 mA max) for powering devices.

• Dual Power Inputs: DC jack or PoE-IN (8–30 V); max consumption 24 W.

• RouterOS v4: Includes full-featured OS with license 4 for advanced configuration.

---

Full Specifications

General

• Product Code: RB951Ui-2HnD

• Architecture: MIPSBE

• CPU: AR9344, 1 core, 600 MHz

• RAM: 128 MB

• Storage: 128 MB NAND

• Dimensions: 113 × 138 × 29 mm

• Weight: 240 g

• MTBF: ~100,000 h @ 25 °C

• Operating Temp: –20 °C to +60 °C

• Certifications: CE, FCC, IC, EAC, RoHS; IP20

• Beeper: Yes

Wireless

• Frequency: 2.4 GHz

• Standards: 802.11b/g/n (Wi-Fi 4)

• Max Data Rate: 300 Mbps

• Chains: 2

• Antenna Gain: 2.5 dBi

• Chip Model: AR9344

• Transmit Power (dBm): 6 Mbps: 30; 54 Mbps: 25; MCS0: 30; MCS7: 23

• Receive Sensitivity: 6 Mbps: –96 dBm; 54 Mbps: –80 dBm; MCS0: –96 dBm; MCS7: –78 dBm

Ethernet

• Ports: 5 × 10/100 Mbps RJ45

Peripherals

• USB Ports: 1 × USB 2.0 Type A

• USB Power Reset: Yes; max current 1 A

Powering

• DC Inputs: 2 (PoE-IN & DC jack)

• DC Jack Voltage: 8–30 V

• Max Power Consumption: 24 W (7 W no attachments)

• Cooling: Passive

PoE

• PoE In: Passive PoE 8–30 V

• PoE Out: Port 5, Passive PoE, max 500 mA
