MikroTik hEX S RB760iGS - High-Performance 5-Port Gigabit Router with SFP, USB, Dual-Core 880MHz CPU, and 256MB RAM



Optimize your wired network with the MikroTik hEX S RB760iGS, a robust and versatile router designed for environments where wireless connectivity is not needed. This advanced router features five Gigabit Ethernet ports, an SFP port for fiber connections, and a powerful dual-core 880MHz CPU with 256MB of RAM. Ideal for both small and medium-sized setups, the hEX S offers exceptional performance and reliability with advanced RouterOS capabilities, including IPsec hardware encryption and The Dude server support.

The MikroTik hEX S stands out with its practical design and impressive specifications. It includes a USB 2.0 port and a microSD slot for additional storage and enhanced data handling. The PoE output on the fifth Ethernet port allows for powering other devices, making it a versatile solution for various networking needs. The device's passive cooling and compact size ensure it remains efficient and unobtrusive in any environment, while its affordability makes it an excellent choice for users requiring advanced features without breaking the bank.

Key Features:

• High-Performance CPU: Equipped with a dual-core 880MHz CPU and 256MB RAM, enabling advanced configurations and smooth operation.
• Gigabit Ethernet and SFP Ports: Includes five Gigabit Ethernet ports and a 1.25Gbit/s SFP cage for flexible connectivity options.
• PoE Output: Provides PoE output on Ethernet port #5 to power other passive PoE devices.
• USB and microSD Slots: Features a USB 2.0 port and a microSD slot for additional storage and improved read/write speeds.
• IPsec Hardware Encryption: Supports IPsec hardware encryption, offering secure data transmission at approximately 470 Mbps.

Specifications:

• Product Code: RB760iGS
• Architecture: MMIPS
• CPU: MT7621A
• CPU Core Count: 2
• CPU Nominal Frequency: 880 MHz
• CPU Threads Count: 4
• Switch Chip Model: MT7621A
• Dimensions: 113 x 89 x 28 mm
• RouterOS License: 4
• Operating System: RouterOS
• Size of RAM: 256 MB
• Storage Size: 16 MB
• Storage Type: FLASH
• MTBF: Approximately 100,000 hours at 25°C
• Tested Ambient Temperature: -40°C to 70°C

Powering:

• Number of DC Inputs: 2 (DC Jack, PoE-IN)
• DC Jack Input Voltage: 12-57 V
• Max Power Consumption: 24 W
• Max Power Consumption Without Attachments: 6 W
• Cooling Type: Passive
• PoE In: 802.3af/at
• PoE In Input Voltage: 12-57 V

PoE-Out:

• PoE-Out Ports: Ether5
• PoE Out: Passive PoE up to 57V
• Max Out Per Port Output (Input 18-30 V): 500 mA
• Max Out Per Port Output (Input 30-57 V): 500 mA
• Max Total Out (A): 500 mA

Ethernet:

• 10/100/1000 Ethernet Ports: 5

Fiber:

• SFP Ports: 1

Peripherals:

• Memory Card Type: microSD
• Memory Cards: 1
• Number of USB Ports: 1
• USB Power Reset: Yes
• USB Slot Type: USB Type A
• Max USB Current (A): 1

Other:

• PCB Temperature Monitor: Yes
• Voltage Monitor: Yes
• Mode Button: Yes
• Beeper: Yes

Certification & Approvals:

• Certification: CE, EAC, ROHS
• IP Rating: IP20

Conclusion:

The MikroTik hEX S RB760iGS delivers a powerful and efficient solution for wired network management. With its combination of high-performance hardware, versatile connectivity options, and practical features, it serves as a reliable choice for various networking environments. Its compact design, coupled with advanced functionalities like PoE output and SFP support, ensures that it meets the demands of both professional and home setups effectively.
