JBL Bar 1300 Soundbar - 11.1.4 Channels and Removable Surround Speakers

Experience cinema-quality sound in the comfort of your home with the JBL Bar 1300 Soundbar. This high-performance soundbar system features 11.1.4 channels and detachable surround speakers, providing a rich and immersive audio experience that brings movies, music, and games to life. Designed to deliver exceptional sound clarity and depth, the JBL Bar 1300 utilizes advanced technology, including powerful racetrack drivers and up-firing full-range drivers, to create a truly cinematic soundscape.

The JBL Bar 1300 is equipped with a total power output of 1170 watts, ensuring that every sound detail is reproduced with stunning accuracy. The system includes a robust soundbar, detachable surround speakers, and a powerful subwoofer, all designed to work seamlessly together. The soundbar features six racetrack drivers and five tweeters, while the detachable surround speakers include additional drivers and passive radiators for an enhanced surround sound experience. With support for the latest wireless technologies and a range of connectivity options, this soundbar system is perfect for enhancing any home entertainment setup.

Key Features:

• 11.1.4 Channel Audio System: Offers an expansive soundstage with 11.1.4 channels, including detachable surround speakers, to deliver immersive audio for movies, music, and gaming.
• Powerful Output: Delivers a total of 1170 watts of power, with 650 watts from the soundbar, 2x 110 watts from the surround speakers, and 300 watts from the subwoofer for deep, impactful sound.
• Advanced Drivers: Features six racetrack drivers, five tweeters, and four up-firing full-range drivers in the soundbar, with additional drivers and passive radiators in the detachable surround speakers for superior sound clarity and depth.
• Wireless Connectivity: Supports Bluetooth 5.0 and 5.2, as well as Wi-Fi (IEEE 802.11 a/b/g/n/ac/ax) for easy streaming and connection to various devices.
• Versatile Inputs: Includes optical, Bluetooth, and USB inputs, with USB playback available in specific versions, catering to different audio sources and formats.

Specifications:

• General Specifications:

  • Sound System: 11.1.4 channel
  • Power Supply: 100 - 240V AC, ~ 50/60Hz
  • Networked Standby Power: < 2.0W
  • Operating Temperature: 0°C - 45°C

• Audio Specifications:

  • Total Speaker Power Output (Max @ THD 1%): 1170W
  • Soundbar Output Power (Max @ THD 1%): 650W
  • Surround Speaker Output Power (Max @ THD 1%): 2x 110W
  • Subwoofer Output Power (Max. @ THD 1%): 300W
  • Soundbar Transducer: 6x (46x90)mm racetrack drivers, 5x 0.75" (20mm) tweeters, 4x 2.75" (70mm) up-firing full-range drivers
  • Surround Speaker Transducer: (46x90)mm racetrack driver, 0.75" (20mm) tweeter, 2.75" (70mm) up-firing full-range driver, 2x (48x69)mm rounded rectangle passive radiators
  • Subwoofer Transducer: 10” (260mm)
  • Frequency Response: 33Hz - 20kHz (-6dB)
  • Audio Inputs: 1 Optical, Bluetooth, USB (USB playback is available in US version; for other versions, USB is for service only.)

• Dimensions:

  • Total Soundbar Dimensions (W x H x D): 1376 x 60 x 139 mm / 54.2" x 2.4" x 5.5"
  • Main Soundbar Dimensions (W x H x D): 1000 x 60 x 139 mm / 39.4" x 2.4" x 5.5"
  • Detachable Surround Speaker Dimensions (each) (W x H x D): 202 x 60 x 139 mm / 8" x 2.4" x 5.5"
  • Subwoofer Dimensions (W x H x D): 305 x 440.4 x 305 mm / 12" x 17.3" x 12"
  • Soundbar Weight: 4.3kg / 9.5 lbs
  • Detachable Surround Speaker Weight (each): 1.25 kg / 2.75 lbs
  • Subwoofer Weight: 10 kg / 22 lbs
  • Packaging Dimensions (W x H x D): 381 x 1107 x 477 mm / 15" x 43.6" x 18.8"
  • Packaging Weight: 21.45 kg / 47.2 lbs

• Control and Connection Specifications:

  • USB Port: Type A
  • USB Rating: 5V DC, 0.5A
  • Supporting File Format: MP3
  • MP3 Codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
  • MP3 Sampling Rate: 16 - 48 kHz
  • MP3 Bitrate: 80 - 320 kbps
  • Bluetooth Version: Main bar - 5.0, Detachable surround speaker - 5.2
  • Bluetooth Profile: Main bar - A2DP 1.2 and AVRCP 1.5, Detachable surround speaker - A2DP 1.3 and AVRCP 1.6
  • Bluetooth Transmitter Frequency Range: 2400 MHz – 2483.5 MHz
  • Bluetooth Transmitter Power: <15 dBm (EIRP)
  • Wi-Fi Network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
  • 2.4G Wi-Fi Transmitter Frequency Range: 2412 - 2472 MHz (2.4GHz ISM Band)
  • 2.4G Wi-Fi Transmitter Power: <20 dBm (EIRP)
  • 5G Wi-Fi Transmitter Frequency Range: 5.15 - 5.35 GHz, 5.470 - 5.725 GHz, 5.725 - 5.825 GHz
  • 5G Wi-Fi Transmitter Power: 5.15-5.25 GHz <23 dBm, 5.25-5.35 GHz & 5.47-5.725 GHz <20 dBm, 5.725-5.825 GHz <14 dBm (EIRP)
  • 2.4G Wireless Frequency Range: 2406 - 2474 MHz
  • 2.4G Wireless Power: <10 dBm (EIRP)

• Battery:

  • Lithium Battery: 3.635V, 6600 mAh
  • Detachable Surround Speaker Playtime: Up to 12 Hours (may vary according to content type and volume level)

Conclusion:

The JBL Bar 1300 Soundbar is a sophisticated home audio solution that merges advanced technology with impressive power output to deliver an exceptional auditory experience. Its 11.1.4 channel configuration, along with detachable surround speakers and a powerful subwoofer, ensures an immersive sound experience that enhances any multimedia content. Designed with a focus on superior sound quality and user convenience, the JBL Bar 1300 stands as a premier choice for those seeking a comprehensive and high-performance soundbar system.
