APC Smart-UPS RT 48V Battery Pack - 2U, Lead-Acid, Black





APC Smart-UPS RT 48V Battery Pack – Reliable Backup Power Solution

The APC Smart-UPS RT 48V Battery Pack is designed to provide reliable and uninterrupted power for your Smart-UPS system. This 2U rackmountable battery pack is equipped with lead-acid batteries, ensuring dependable backup power and enhanced runtime for critical applications.

Key Features:

• Battery Type: Lead-acid
• Battery Voltage: 48 V
• Number of Battery Slots: 2 filled, 0 free
• Replacement Battery: RBC31
• Mounting Mode: Not rack-mountable
• Output Wave Type: Sine wave
• Crest Factor: 3:1
• Harmonic Distortion: Less than 3%
• Output Frequency: 50/60 Hz +/- 3 Hz, user adjustable +/- 0.1 Hz sync to mains
• Bypass Type: Built-in static bypass

Physical Characteristics:

• Height: 8.5 cm
• Width: 43.2 cm
• Depth: 48.3 cm
• Net Weight: 29.56 kg
• Color: Black

Provided Equipment:

• Installation guide
• User manual

Environmental Conditions:

• Operating Temperature: 0 to 40 °C
• Storage Temperature: -15 to 45 °C
• Relative Humidity (Operation): 0 to 95 %
• Relative Humidity (Storage): 0 to 95 %
• Operating Altitude: Up to 10,000 ft
• Storage Altitude: Up to 15,240 m

Packing Details:

• Unit Type of Package 1: PCE
  • Number of Units in Package 1: 1
  • Package Dimensions: Height 28.6 cm, Width 63 cm, Length 59.4 cm
  • Package Weight: 32.28 kg
• Unit Type of Package 2: PAL
  • Number of Units in Package 2: 12
  • Package Dimensions: Height 135 cm, Width 100 cm, Length 120 cm
  • Package Weight: 420 kg

Additional Information:

• Replace all batteries in operation together (UPS internal and external batteries) all-at-once for optimal performance.

The APC Smart-UPS RT 48V Battery Pack offers robust protection and extended runtime, essential for maintaining high availability and performance in demanding environments.
